Phoenix Contact 1907539 Spring-loaded terminal 4.00 mm² Number of pins 1 Green 50 pc(s)
EAN:
Part number:
Item no:
Product type
Spring-loaded terminal
CS
10 mm
Pins per row
1
Number of pins
1
Connection
Spring-loaded terminal
Print
Datasheet (PDF)
Number (Package size 50 pc(s))
Total (€ 0.74 / piece)
€ 36.97
plus VAT.
14-day return policy included
Highlights & Details
PCB terminal block ZFKDS 4-10
- Content 50 pc(s)
Technical specifications
- Type
ZFKDS 4-10
- Product type
Spring-loaded terminal
- CS
10 mm
- No. of rows
1
- Pins per row
1
- Number of pins
1
- Series
ZFKDS(A)
- Min. stripping length
10 mm
- Stripping length (max.)
10 mm
- Connection
Spring-loaded terminal
Print
- Nominal current
32 A
- Cross section (flexible) (min.)
0.20 mm²
- Nominal current - rounded value
32 A
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
4.00 mm²
- Cross section (inflexible) (max.)
6.00 mm²
- AWG (min.)
24
- Connector orientation
At an angle (to the PCB)
- AWG max.
10
- Contact material
Cathode copper, tin plated
- Enclosure material
Polyamide 6.6
- Factory colour
Green
- Wire protection
Yes
- Manufacturer part #
1907539
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
630 V
- Width
29.00 mm
- Height
27.60 mm
- Length
11.50 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 193757 Phoenix Contact 1907539 Spring-loaded terminal 4.00 mm² Number of pins 1 Green 50 pc(s)
User & Safety Instructions
User & Safety Instructions 193757 Phoenix Contact 1907539 Spring-loaded terminal 4.00 mm² Number of pins 1 Green 50 pc(s)
Description
PCB terminal block, Nominal current: 32 A, Nom. voltage: 630 V, Pitch: 10 mm, Number of positions: 1, Connection method: Spring-cage conn., Mounting: Soldering, Conductor/PCB connection direction: 45 °, Color: green, The article can be aligned to create different nos. of positions!
