Image similar
Image similar
Schneider Electric RSL1PVBU Plug-in relay 24 V DC, 24 V AC 6 A 1 change-over 1 pc(s)
EAN:
Part number:
Item no:
Product type
Plug-in relay
Contact type
1 change-over
Nominal voltage
24 V DC
24 V AC
Switching voltage (max.)
277 V DC
277 V AC
Switching current (max.)
6 A
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 18.48
3
5% = € 0.92
€ 17.56
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 18.48 / piece)
€ 18.48
plus VAT.
Plug-in relay series RSL
Technical specifications
- Product type
Plug-in relay
- Type
RSL1PVBU
- Connection
Screw terminal
- Factory colour
Anthracite (matt)
- Contact type
1 change-over
- Contact material
AgSnO2
- Nominal voltage
24 V DC
24 V AC
- Switching voltage (max.)
277 V DC
277 V AC
- Switching current (max.)
6 A
- Max. switching capacity
1500 VA
- Durability
1000 0000 cycles
- Features
+ diode bridge
+ bracket
+ LED
IP40
- Max. temperature
+70 °C
- Min. temperature
-40 °C
- Depth
78.6 mm
- Width
6.2 mm
- Height
95 mm
- Dim
(W x H x D) 6.2 x 95 x 78.6 mm
- Content
1 pc(s)
- Weight
29 g
6 A
6.2
78.6 mm
95 mm
TRUE
Polarity free
Mono stable
TRUE
Single contact
TRUE
Screw connection
24-24 V
24-24 V
24-24 V
Other
IP40
TRUE
Other
AC/DC
0
0
1
Other
- UKCA
yes
