Buy Stabila TECH 196 DL 19827 Digital level incl. anti-slip pad, incl. bag 100 cm 0.5 mm/m

Yellow digital spirit level with built-in display in the centre and two bubble vials at the ends for alignment measurement.

Yellow spirit level with digital display and bubble vials for measuring inclination. Suitable for construction and DIY work.

Spirit level with digital display and bubble vials for precise angle measurement, yellow casing, red handle, 61 cm long.

Yellow spirit level on a white background, with a removable red end cap and a round bubble vial for measuring alignment.

Digital angle gauge with green display, showing value '0.00'. Yellow casing with water droplet symbol and multiple function buttons.

Electronic spirit level with digital display and bubble vial, Yellow. Manufacturer: Stabila, from Germany. Display shows zero alignment.

A construction site with four yellow spirit levels leaning against brick walls shows an ongoing building construction.

A person is checking the spirit level in a yellow concrete mixing bowl filled with water. Bricks can be seen in the background.

A man is kneeling on a building site and using a spirit level to level a surface. Building equipment and a brick house are in the background.

'A worker is kneeling on black gravel and using a spirit level to align the surface for paving work.'

A person is using a spirit level to install a plasterboard wall in an unfinished room.

An older man is measuring a wall with a spirit level in a renovated room. He is wearing checked clothing and looks focused.

A person is working on a building site, surrounded by wooden scaffolding. They are using a tool to ensure that beams are level.

A construction worker in protective gear is mixing mortar in a container on a building site surrounded by brick walls.

1/15

Datasheet (PDF)

Fast track dispatch on Mon, 14 Sep

16 Piece(s)

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 201.67 / piece)

€ 201.67

plus VAT.

Report legal concerns

Highlights & Details

Stabila digital spirit level TECH 196 DL, 100 cm, water and dust proof according to IP 67, 2 digital displays, calibration-free, DISPLAY-modes °, %, mm/m, in/ft

23 cm
super compact
100% digital – particularly suitable for aligning short components.

Technical specifications

Measuring accuracy in normal position: 0.50 mm/m
Measurement accuracy in transshipment position: 0.50 mm/m.
Accuracy of electronic tilt measurement at 0° and 90° +/-: 0.05°
Accuracy of electronic tilt measurement at 1° to 89° +/-: 0.10°
IP67 protection class

Product type: Digital level

Features: incl. anti-slip pad
incl. bag

Length: 100 cm

Level accuracy: 0.5 mm/m

Material: Aluminium

Power supply (details): 2x AA batteries

Weight: 0

Type: TECH 196 DL

Factory colour: Multicolour

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2980198 Stabila TECH 196 DL 19827 Digital level incl. anti-slip pad, incl. bag 100 cm 0.5 mm/m

User & Safety Instructions

User & Safety Instructions 2980198 Stabila TECH 196 DL 19827 Digital level incl. anti-slip pad, incl. bag 100 cm 0.5 mm/m

Warranty Terms

Warranty Terms 2980198 Stabila TECH 196 DL 19827 Digital level incl. anti-slip pad, incl. bag 100 cm 0.5 mm/m

Description

Water, dust, dirt and shocks - tools have to put a lot away. The electronic water-level TECH 196M DL from Stabila is best equipped for the daily work on construction sites Thanks to ULTRA-PROTECT, it is easy to clean under water and the high-precision electronic module does not need to be calibrated after falls or temperature fluctuations. Clever features of this quality product Made in Germany simplify every measurement task: Two digital displays with switchable illumination, acoustic target guiding, extra-strong rare-earth magnets as well as numerous display modes.

This text is machine translated.

Features

Electronic spirit level with two digital displays for delay-free measurement of slope and slope.
ULTRA-PROTECT: Optimal protection against dust and water according to IP 67 - the spirit level can be temporarily immersed.
Two digital displays, illuminated at the push of a button.
Acoustic target guiding: For a quick alignment of components, without looking at the spirit level – with two different signal tones.
CAL-FREE: Electronics calibration is not necessary in daily use – even after a fall or temperature change.
Digital display rotates in envelope position.
REF-MODE: Apply, save, and transfer an angle measurement to other components.
KEY-LOCK: Keypad lock to protect against accidental inputs.
Display modes: °, %, mm/m, in/ft - decimal and as break.
Long operating time: Up to 400 hours.
Including bag for a safe transportation
