Buy TracoPower TML 100-115C AC/DC PSU (print) 5.7 A 85 W

Datasheet (PDF)

Available soon

Sales and shipping:

Conrad Electronic Terms & Conditions

Number

Piece(s)

Total (€ 168.06 / piece)

€ 168.06

plus VAT.

Report legal concerns

Highlights & Details

AC / DC power supply module TML series, 5 - 30 watts

Output / 5.7 A
Power 85 W
Input voltage 85 - 264 V AC
Screw terminal

Technical specifications

max. 120 - 180 % (foldback)

Product type: AC/DC PSU (print)

Max. output current: 5.7 A

Output current (max.) - rounded: 5.7 A

Dim: (L x W x H) 62 x 140 x 36.6 mm

Connection: Screw terminal

: 85 W

Efficiency to: 91.5 %

Tolerance (output voltage): 5 %

Protection class: II

No. of outputs: 1 x

Output voltage 1: 15 V DC

Operating temperature (max.): +70 °C

Max. operating temperature (derating): +50 °C

Operating temperature (min.): -25 °C

Operating temperature: -25 to +60 °C

Weight: 440 g

Insulation voltage: 3000 V AC

PSU features: Adjustable voltage output

Width: 140 mm

Height: 36.6 mm

Length: 62 mm

Residual ripple: Max 1.5 %

Type: TML 100-115C

Input voltage: 85 - 264 V AC

Mains control: max. ±0.3 %

Documents & Downloads

Datasheet

Datasheet 2789983 TracoPower TML 100-115C AC/DC PSU (print) 5.7 A 85 W

User & Safety Instructions

User & Safety Instructions 2789983 TracoPower TML 100-115C AC/DC PSU (print) 5.7 A 85 W

Warranty Terms

Warranty Terms 2789983 TracoPower TML 100-115C AC/DC PSU (print) 5.7 A 85 W

Description

AC/DC-power supply module in cast plastic casing. Wide-range input for worldwide usage. High degree of efficiency, low noise and low remaining ripple. Short-circuit and overload protection. Radio interference suppression acc. EN 55022, class B and FCC, Level B UL 94V-0. Security in accordance with UL 1950, IEC / EN 60950 3 years warranty.
