Buy TracoPower TML 20115C AC/DC PSU (print) 15 V DC 1.34 A 20 W

'TRACO Power Module TML 20115': Input range 100-240 VAC, output 5 VDC/3,000 mA. Rectangular electronic component with pins.

Datasheet (PDF)

Sales and shipping:

Number

Piece(s)

Minimum order quantity: 10

Total (€ 67.22 / piece)

€

Report legal concerns

Highlights & Details

AC / DC power supply module TML series, 5 - 30 watts

Output 15 V DC / 1.34 A
Power 20 W
Input voltage 85 - 264 V AC

Technical specifications

max. 120 - 180 % (foldback)

Product type: AC/DC PSU (print)

Input voltage (max.): 264 V AC

Max. output current: 1.34 A

Output current (max.) - rounded: 1.34 A

Min. input voltage: 85 V AC

Dim: (W x H) 55 mm x 28 mm

Output voltage (max.): 15 V DC

: 20 W

No. of outputs: 1 x

Output voltage 1: 15 V

Output current 1: 1340 mA

Operating temperature: -25 to +60 °C

Insulation voltage: 3000 V AC

Width: 55 mm

Height: 28 mm

Residual ripple: Max 1.5 %

Type: TML 20115C

Input voltage: 85 - 264 V AC

Mains control: max. ±0.3 %

Documents & Downloads

Datasheet

Datasheet 3370022 TracoPower TML 20115C AC/DC PSU (print) 15 V DC 1.34 A 20 W

User & Safety Instructions

User & Safety Instructions 3370022 TracoPower TML 20115C AC/DC PSU (print) 15 V DC 1.34 A 20 W

Warranty Terms

Warranty Terms 3370022 TracoPower TML 20115C AC/DC PSU (print) 15 V DC 1.34 A 20 W

Description

AC/DC-power supply module in cast plastic casing. Wide-range input for worldwide usage. High degree of efficiency, low noise and low remaining ripple. Short-circuit and overload protection. Radio interference suppression acc. EN 55022, class B and FCC, Level B UL 94V-0. Security in accordance with UL 1950, IEC / EN 60950 3 years warranty.
