WAGO 254-856 Spring-loaded terminal 1.50 mm² Number of pins 1 Orange 400 pc(s)
Product type
Spring-loaded terminal
CS
7.50 mm
7.62 mm
Pins per row
1
Number of pins
1
Connection
Spring-loaded terminal
Print
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 400 pc(s))
Total (€ 0.45 / piece)
€ 179.99
incl. VAT
14-day return policy included
Highlights & Details
1-conductor PCB terminal block
- Content 400 pc(s)
Technical specifications
- TERMINAL BLOCK - ORANGE
- Type
254-856
- Product type
Spring-loaded terminal
- Features
+ PUSH WIRE®
- CS
7.50 mm
7.62 mm
- Pins per row
1
- Number of pins
1
- Series
254
- Min. stripping length
8 mm
- Stripping length (max.)
10 mm
- Connection
Spring-loaded terminal
Print
- Cross section (flexible) (min.)
0.50 mm²
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
1.50 mm²
- Cross section (inflexible) (max.)
2.50 mm²
- AWG (min.)
20
- Connector orientation
At an angle (to the PCB)
- AWG max.
12
- Contact material
Cathode copper, tin plated
- Factory colour
Orange
- Wire protection
Yes
- Manufacturer part #
254-856
- Industrial packaging
Yes
- Content
400 pc(s)
- Nominal voltage
630 V
- Width
19.70 mm
- Height
13.50 mm
- Length
9.20 mm
Documents & Downloads
Datasheet
Datasheet 747546 WAGO 254-856 Spring-loaded terminal 1.50 mm² Number of pins 1 Orange 400 pc(s)
User & Safety Instructions
User & Safety Instructions 747546 WAGO 254-856 Spring-loaded terminal 1.50 mm² Number of pins 1 Orange 400 pc(s)
