WAGO 261-344 Terminal 10 mm Pull spring Configuration: N Blue 200 pc(s) Package

Grey electrical terminal block with two connection openings and integrated metal contact. Used for securely connecting cables.
Packaging type
Package
Product type
Terminal
Connection
Pull spring
Cross section (flexible) (max.)
2.50 mm²
Cross section (inflexible) (max.)
2.50 mm²
Datasheet (PDF)
EAN:
Part number:
Item no:
Dispatches on Fri 20 Nov
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number (Package size 200 pc(s))
Total (€ 1.07 / piece)
€ 214.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Highlights & Details

4-conductor terminal block

  • 261-344
  • 200 pieces/bag

Technical specifications

  • 4-COND.T.B. 2.5SQMM BLUE W.FIX.FT
Packaging type

Package

Product type

Terminal

Features

+ latch lock base

Complies with ATEX Ex I standards

Connection

Pull spring

Configuration

N

Cross section (flexible) (min.)

0.08 mm²

Cross section (flexible) (max.)

2.50 mm²

Cross section (inflexible) (min.)

0.08 mm²

Cross section (inflexible) (max.)

2.50 mm²

AWG (min.)

28

AWG max.

14

Clamp width

10 mm

No. of rows

1

Pins per row

4

Number of pins

4

Factory colour

Blue

Nominal current

24 A

Nominal current - rounded value

24 A

Nominal voltage

500 V

Min. stripping length

8 mm

Stripping length (max.)

9 mm

Manufacturer part #

261-344

Content

200 pc(s)

Industrial packaging

Yes

Type

261-344

Dim

(W x H) 10 mm x 18 mm

Width

10 mm

Height

18 mm

Contamination level

3

Connector colour

Blue

Documents & Downloads

Datasheet

Datasheet 533872 WAGO 261-344 Terminal 10 mm Pull spring Configuration: N Blue 200 pc(s) Package

User & Safety Instructions

User & Safety Instructions 533872 WAGO 261-344 Terminal 10 mm Pull spring Configuration: N Blue 200 pc(s) Package

Description

With snap-in base, plate thickness 0409 14.2 mm, mounting hole Ø 3.5 mm, even on aluminum rail 210-154 or 209-120 with mounting base on TS 35, complies with ATEX Ex i, blue.
