Image similar
Barthelme ECOline 300-1400mA 1-10V LED converter 40 W 32 V DC Max. operating voltage: 240 V AC
Product type
LED converter
Power
40 W
Connection
Screws
Output voltage (max.)
32 V DC
Min. operating voltage
110 V AC
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 40.99 / piece)
€ 40.99
incl. VAT
Only 5 Piece(s) available
Technical specifications
- Product type
LED converter
- Type
ECOline 300-1400mA 1-10V dimmable
- Operating voltage
110 - 240 V AC
40 W
- For LEDs
4 – 9 high-power LEDs 300 – 1400 mA
- No. of LEDs (max.)
9
- Connection
Screws
- Min. temperature
-25 °C
- Max. temperature
60 °C
- Dim
(L x W x H) 156 x 42 x 32 mm
- Height
32 mm
- Length
156 mm
- Width
42 mm
- Output current (min.)
300 mA
- Output voltage (max.)
32 V DC
- Output voltage (min.)
16 V DC
- Min. operating voltage
110 V AC
- Max. operating voltage
240 V AC
- RoHS-compliant
Yes
40 W
- Output voltage
16 - 32 V
- Output current (details)
300 - 1400 mA
- Temperature range
-25 - +60 °C
- Operating voltage
110 - 240 V AC
- UKCA
not relevant
Documents & Downloads
Datasheet
Datasheet 181972 Barthelme ECOline 300-1400mA 1-10V LED converter 40 W 32 V DC Max. operating voltage: 240 V AC
User & Safety Instructions
User & Safety Instructions 181972 Barthelme ECOline 300-1400mA 1-10V LED converter 40 W 32 V DC Max. operating voltage: 240 V AC
Description
This converter is characterized by a very good degree of efficiency of 97%. This means that in combination with LEDS, lighting solutions with a high lumen/watt efficiency can be implemented.
Features
- Dimming function via signal 1 – 10 V.
Hints
The output current (300 – 1400 mA) is set by resistors. Please refer to the table in the data sheet.
