Name: Brennenstuhl 1170910 Wall Motion detector 240 ° White IP44
Brand: Brennenstuhl
SKU: 2194467
Availability: InStock

Two white security motion sensors, one cylindrical ceiling-mounted unit and one rectangular infrared sensor housing with twin lenses.

Datasheet (PDF)

EAN:

Part number:

Item no:

Fast track dispatch on Wed 4 Nov

38 Piece(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 16.99 / piece)

€ 16.99

incl. VAT

14-day return policy included

Report legal concerns

Alternative article by SYGONIX

Sygonix SY-6733030 Wall, Surface-mount PIR motion detector 240 ° Relay White IP65

Fast track dispatch on Wed 4 Nov

€ 11.99

incl. VAT plus

Highlights & Details

Brennenstuhl motion detector infrared / movement sensor for exterior and interior.

Infrared motion detector with an adjustable brightness (10 - 150 Lux) and duty cycle (10 sec. - 4 min)
The breaking capacity is for: Incandescent bulbs max. 1000 Watt - energy saving lamps max. 300 Watt - LED lamps max. 100 Watt
Outdoor motion sensor with 240 ° horizontal detection angle and max. 12 m range
For automatic on and off of lights, halogen lamps, energy saving lamps and LED lamps

Technical specifications

Product type: Motion detector

Detection angle: 240°

: 12 m

Used at: Outdoors
Indoors

Mounting type: Wall

Operating voltage: 230 V

Switching capacity: 1000 W

Switching capacity (energy saving bulbs): 300 W

Switching capacity (LED): 100 W

Twilight settings: 10 - 150 lx

Time settings: 10 s - 4 min

Factory colour: White

: IP44

Operating temperature: -20 °C to 40°C °C

Length: 220 mm

Width: 120 mm

Height: 80 mm

Dim: (L x W x H) 220 x 120 x 80 mm

Weight: 0.36

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 2194467 Brennenstuhl 1170910 Wall Motion detector 240 ° White IP44

User & Safety Instructions

User & Safety Instructions 2194467 Brennenstuhl 1170910 Wall Motion detector 240 ° White IP44

Description

The Brennenstuhl PIR 240 IP44 infrared motion detector is an automatic motion sensor with a detection angle of 240° and a maximum range of 12 meters. It is suitable for use indoors and outdoors (IP44). The duty cycle can be flexibly controlled from approx. 10 seconds up to approx. 4 minutes. It also impresses with the following features:

* Response brightness adjustable from 10 - 150 Lux
* Switching capacity max. 1000 watts (light bulb), max. 300 watts (energy-saving bulb) or max. 100 watts (LED)
* Vertically and horizontally adjustable
* With corner bracket
* Voltage 230 V.

This text is machine translated.
