Renkforce RF-4216076 Flush mount HF motion detector 180 ° Relay White IP20
EAN:
Part number:
Item no:
Number
Total (€ 12.99 / piece)
€ 12.99
incl. VAT
14-day return policy included
Highlights & Details
Microwave Motion Sensor (Square, White)
- Adjustable ambient light activation
Technical specifications
- Product type
HF motion detector
- Detection angle
180°
15 m
- Used at
Indoors
- Mounting type
Flush mount
- Operating voltage
230 V AC
- Contact type
Relay
- Switching capacity
1200 W
- Switching capacity (energy saving bulbs)
300 W
- Switching capacity (light bulbs)
1200 W
- Switching capacity (halogen bulbs)
1200 W
- Switching capacity (LED)
300 W
- Standby current consumption
0.63 W
- Twilight settings
3-2000 lx
- Time settings
10 s - 12 min
- Factory colour
White
IP20
- Operating temperature
-20 to +50 °C
- Length
80 mm
- Width
80 mm
- Height
32 mm
- Dim
(L x W x H) 80 x 80 x 32 mm
- Weight
0.1 kg
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2108038 Renkforce RF-4216076 Flush mount HF motion detector 180 ° Relay White IP20
Conformity certificate
Conformity certificate 2108038 Renkforce RF-4216076 Flush mount HF motion detector 180 ° Relay White IP20
Description
The sensor works with high-frequency technology transmitting an inaudible signal able to penetrate doors, glass panels and thin walls.
Due to its wide detection angle (180°) and range (5-15m), this senor is ideal for a huge variety of areas, staircases and complex room layouts regardless of the temperature in the monitored area.
The motion sensor can be activated by ambient light ranging from <3 to 2000 lux, with a time delay between 10 seconds and 12 minutes.
This high-quality sensor has been specially designed for resistive loads of up to 1200W, and inductive loads of up to 300W. Using the sensor to automatically switch on and off appliances frees up plenty of time.
Due to its wide detection angle (180°) and range (5-15m), this senor is ideal for a huge variety of areas, staircases and complex room layouts regardless of the temperature in the monitored area.
The motion sensor can be activated by ambient light ranging from <3 to 2000 lux, with a time delay between 10 seconds and 12 minutes.
This high-quality sensor has been specially designed for resistive loads of up to 1200W, and inductive loads of up to 300W. Using the sensor to automatically switch on and off appliances frees up plenty of time.
Features
- Detection range: 180°
- HF system: 5.8GHz CW radar, ISM band
- Detection distance: 5-15m (adjustable)
- Time delay: 10sec±3sec to 12min±1min (adjustable)
- Ambient light: <3-2000 lux (adjustable)
- Maximum resistive load: 1200W
- Maximum inductive load: 300W
Scope of delivery
- Motion detector
- Operating instructions
