HARTING 09200162612 Pin inset Han® A 16 + PE Screws 1 pc(s)
EAN:
Part number:
Item no:
Number of pins
16
Type
Han® 16A-STi-S
Manufacturer part #
09200162612
Factory colour
Grey
Connection
Screws
Datasheet (PDF)
Quantity (Piece(s))
Savings
Package size (plus VAT.)
1
-
€ 31.92
3
4% = € 1.38
€ 30.54
Volume discounts vary depending on the seller
You save € 0.00
Number
Total (€ 31.92 / piece)
€ 31.92
plus VAT.
Highlights & Details
HARTING 09200162612 Pin inset Han® A 16 + PE Screws 1 pc(s)
Technical specifications
- Type
Han® 16A-STi-S
- Manufacturer part #
09200162612
- Factory colour
Grey
- Number of pins
16
- Connection
Screws
- Total no. of pins
16 + PE
- Content
1 pc(s)
- Max. temperature
+125 °C
- Leading contact (PE)
Yes
- Size
16 A
- Series
1 - 16
- Features
copper-plated
- Series
Han® A
- Type
Pin insert
- Core cross section (max.)
2.5 mm²
- Core cross section (min.)
1 mm²
- Test current
10 A
- Core connector
1 -2.5 mm²
- Rated voltage
400 V
- Contamination level
3
- Pins
16 + PE
- Connection
Screws
- Mating cycles
≥ 500
- Temperature range
-40 - +125 °C
- Min. temperature
-40 °C
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 741216 HARTING 09200162612 Pin inset Han® A 16 + PE Screws 1 pc(s)
User & Safety Instructions
User & Safety Instructions 741216 HARTING 09200162612 Pin inset Han® A 16 + PE Screws 1 pc(s)
Description
Connectors for high environmental requirements; loking clamp ensures high mechanical stability even under vibration or shock loads. Applicable in: Mechanical engineering, wind energy, switches cabinet construction, train technology.
Hints
Consisting of 2 each 16-pin inserts. Suitable correspondent part is the order number. 74 12 36
