Number
Highlights & Details
Wi-Fi IP-Bullet camera;2560 x 1440 p;INSTARIN-9408 2K+ LAN/WLAN schw.;101664
- Sony STARVIS SENSOR 2K+ Starlight CMOSArtificial Intelligence - AI based object detectionPassive IR sensor: Heat-sensitive motion sensorMotion detection: Software-based detection
Technical specifications
- Angle of view 90° diagonalSensor 8.5 mm (1/3”) WQHD Sony STARVIS IMX335 CMOS sensorInfrared LEDs: 5 high-power LEDs/15 - 20 m effective rangeVideo encoding: H.264 / H.264 high, main and baseline / MJPEGVideo refresh rate: Up to 25fpsSupported resolutions: 2560x1440, 1920x1080 and 680x360 pixelsPower supply output: 12V DC 2A/input: 110 - 240 V.WLAN frequency band: 2.4 GHz and 5 GHz WLAN
- Product type
CCTV camera
- CCTV features
Saves footage on SD card
IR LEDs
Vehicle recognition
Identity recognition
Microphone
ONVIF support
- Camera type
Bullet camera
- Resolution (max.)
2560 x 1440 p
- Sensor size
8.5 mm (1/3")
- Sensor type
CMOS Sony
Apple HomeKit
Alexa
Google Home
Manufacturer-specific
- Focal length
4,3 mm
- App compatibility
Yes
- Transfer type
Wi-Fi
- Wi-Fi standard
IEEE802.11ac
- IR range (max.)
20 m
- Type
microSD card (up to 128 GB)
- Width
75 mm
- Height
103 mm
- Depth
230 mm
- Dim
(W x H x D) 75 x 103 x 230 mm
- Weight
900 g
- F-numbers
F1.6
- Factory colour
Black
IP66
- Signal standard
IP
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2625710 INSTAR IN-9408 2K+ LAN/WLAN schw. 101664 Wi-Fi IP CCTV camera 2560 x 1440 p
Description
This text is machine translated.
Features
- IP66 weather-protectedPUSH Alarm: PUSH notification to your smartphoneWLAN encryption: Latest WPA2 encryption (WPA/WPA2-PSK (AES, CCMP)Apple home kit: Integrate the IP camera directly into the home APPMQTT: Native smart home support with MQTTFree apps for your smartphoneHTTPS & FTPS & SFTP: Encrypted DDNS-access, email & FTP-transferUser management: Administrator, user and guest accountsPet monitor: Built-in sound detectionPhoto series: Single images via FTP(S)/SFTP/SD at adjustable time intervalVideo recording: Saves alarm videos to the internal SD cardMicroSD card slot: For MicroSD-/SDXC-cards up to 128 GBAlarm Schedule: Alarm activation by scheduleDDNS & P2P: P2P remote access also via IPv6 and DS-Lite Internet connectionsBuilt-in microphoneSpeaker (optional): Optional connection possible thanks to 3.5 mm jack plugPrivacy: Black areas that you are not allowed to recordAlarm areas: Up to 4 adjustable motion detection areasFTP upload to e.g. B. External storage (NAS/router)Alarm forward: Recording with 3 s delayModern WebUI: Web user interface for an easy configurationAlarm signal: Alarm sound if an opt. Loudspeakers is connectedOptional cloud integration: Store your alarm videos on our cloud platform.
Scope of delivery
- Camera
- Mount
- Antenna
- 32 GB MicroSD (already inserted in camera)
- Power supply, 3 m
- Network cable
- Fitting Material
- User manual.
System requirements
- Web browser with HTML5 support.
