Name: Secatec MKF30AUAK Reed switch 1 change-over 150 V DC, 150 V AC 1 A 20 VA
Brand: Secatec
SKU: 505371
Availability: InStock

Highlights & Details

Secatec MKF30AUAK Reed switch 1 change-over 150 V DC, 150 V AC 1 A 20 VA

Technical specifications

Service life: 105 - 106 operations
Protection class IP67

Product type: Reed switch

Type: MKF30AUAK

Contact type: 1 change-over

Switching voltage (max.): 150 V DC
150 V AC

Switching current (max.): 1 A

Max. switching capacity: 20 VA

Connection: Open end cable

Cable length: 1.00 m

Enclosure material: Plastic

Max. temperature: +70 °C

Min. temperature: -30 °C

Width: 60 mm

Height: 70 mm

Length: 70 mm

Dim: (L x W x H) 70 x 60 x 70 mm

Documents & Downloads

Datasheet

Datasheet 505371 Secatec MKF30AUAK Reed switch 1 change-over 150 V DC, 150 V AC 1 A 20 VA

User & Safety Instructions

User & Safety Instructions 505371 Secatec MKF30AUAK Reed switch 1 change-over 150 V DC, 150 V AC 1 A 20 VA

Description

Classic fork design, any switching function is possible by changing contact.

This text is machine translated.

Hints

The reed switch is not suitable for direct switching of lights, power supplies, drives, etc., as the maximum permissible current is often exceeded during the switching on/off process. Please use an additional coupling relay with protective circuit.
