Secatec 75385 MKF19XUAK N/A
EAN:
Part number:
Item no:
Product type
Reed switch
Contact type
1 change-over
Switching voltage (max.)
30 V DC
30 V AC
Switching current (max.)
0.2 A
Connection
Open end cable
Datasheet (PDF)
Number
Total (€ 36.13 / piece)
€ 36.97
€ 36.13
plus VAT.
Highlights & Details
Secatec 75385 MKF19XUAK N/A
Technical specifications
- Life: 10 5 - 10 6 switching cycles
- Product type
Reed switch
- Type
MKF19XUAK
- Features
+ mounting holes
- Contact type
1 change-over
- Switching voltage (max.)
30 V DC
30 V AC
- Switching current (max.)
0.2 A
- Max. switching capacity
3 VA
- Connection
Open end cable
- Cable length
1.00 m
- Enclosure material
Plastic
- Max. temperature
+130 °C
- Min. temperature
-40 °C
- Width
19 mm
- Height
10.5 mm
- Length
28.5 mm
- Dim
(L x W x H) 28.5 x 19 x 10.5 mm
Documents & Downloads
Datasheet
Datasheet 505367 Secatec 75385 MKF19XUAK N/A
User & Safety Instructions
User & Safety Instructions 505367 Secatec 75385 MKF19XUAK N/A
Conformity certificate
Conformity certificate 505367 Secatec 75385 MKF19XUAK N/A
Certificate
Certificate 505367 Secatec 75385 MKF19XUAK N/A
Certificate 505367 Secatec 75385 MKF19XUAK N/A
Description
ATEX-certified reed sensor in the stable housing. Approval (ATEX) II 2 G EX MB II T6, kema 02 ATEX 1288 X, (IECEx) Ex mb II T6, IECEx KEM 08.0009 X.
This text is machine translated.
This text is machine translated.
Hints
The reed switch is not for the direct switching of lighting, power supplies, drives, etc., as the maximum permissible current is often needed when switching on/off operation is exceeded. Please an additional interface relay with protective circuit.
