Theben 4061753 Wall PIR motion detector 150 ° White IP54
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 61.99 / piece)
€ 61.99
incl. VAT
Only 7 Piece(s) available
Highlights & Details
Theben theLuxa S150 WH motion detector
- 150° detection angle
- For outdoor use
- Pulse function
Technical specifications
- Setting range for brightness: 5 - 1000 lx
- Switch-on current (max.): 300 A/200 μs
- II proctection rating.
- Product type
PIR motion detector
- Detection angle
150°
12 m
- Used at
Outdoors
- Mounting type
Wall
- Operating voltage
230 V
- Switching capacity (light bulbs)
2300 W
- Switching capacity (halogen bulbs)
2300 W
- Switching capacity (LED)
25 W - 100 W
- Switching capacity (light tubes)
600 W
- Standby current consumption
0.9 W
- Twilight settings
5 - 1000 lx
- Time settings
1 sec. - 20 Min.
- Factory colour
White
IP54
- Operating temperature
-25 °C - +45 °C
- Length
127 mm
- Width
85 mm
- Height
99.6 mm
- Dim
(L x W x H) 127 x 85 x 99.6 mm
- Weight
0.2890 kg
Surface mounted (plaster)
White
100
Movement sensor
FALSE
85 mm
127 mm
Screwed terminal
Untreated
AC
50-50 MHz
TRUE
Thermoplastic
10 A
Plastic
9010
IK04
230-230 V
IP55
FALSE
Matt
FALSE
FALSE
FALSE
FALSE
FALSE
FALSE
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 1610223 Theben 4061753 Wall PIR motion detector 150 ° White IP54
User & Safety Instructions
User & Safety Instructions 1610223 Theben 4061753 Wall PIR motion detector 150 ° White IP54
Description
Automatic lighting control, depending on the presence and brightness. Sensor head can be rotated to ±90° horizontally and downwards by 30° tilting. Mixed light measurement suitable for the control of fluorescent, incandescent and halogen lamps and LEDs. Zero-voltage switching for relay-gentle switching and high lamp loads.
This text is machine translated.
This text is machine translated.
Features
- Additional low-level detection
- Brightness switching value and delay time can be set
- Teach-in of the current brightness value
- Test function to check the detection range.
- Mounting Flush-mounted socket (60 mm) is possible.
- One-hand socket mounting
- Immediate start-up through pre-setting possible
- Setting elements protected attached
- Blind terminal for protective conductor.
