HOMEPILOT 10132360 RolloTron classic - Power Electric belt winder 23 mm Tensile force (max.) 60 kg Flush mount
EAN:
Part number:
Item no:
Number
Total (€ 193.27 / piece)
€ 193.27
plus VAT.
Only 6 Piece(s) available
Highlights & Details
HOMEPILOT Electric belt winder RolloTron classic - Power 23 mm
- Drive and control in one device.Memory functionDisplay with illuminated symbol-LEDsMax. Traction output 60 kgFor a belt width of 23 mm
Technical specifications
- Delayed travel 0.4 UMax. Switching times 2Operation at: +0°C to +40°C.Connection cable: Cable length 1.5 m.Belt length max. 15 m.
- Product type
Electric belt winder
- Belt width
23 mm
- Nominal torque
14 Nm
- Weight
1252 g
- Mounting type
Flush mount
- Nominal power
70
- Operating voltage
230 V
- Aperture size
60 x 274 x 27 mm
- Factory colour
Ultra white
- Assembly dimensions
35 x 196 x 180 mm mm
- Dim
(W x H x D) 60 x 271 x 166 mm
- Hub
Not required
- Belt length
15 m
- Width
60 mm
- Height
271 mm
- Depth
166 mm
- Tensile force (max.)
60 kg
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 2827216 HOMEPILOT 10132360 RolloTron classic - Power Electric belt winder 23 mm Tensile force (max.) 60 kg Flush mount
Warranty Terms
Warranty Terms 2827216 HOMEPILOT 10132360 RolloTron classic - Power Electric belt winder 23 mm Tensile force (max.) 60 kg Flush mount
Description
The RolloTron classic Power belt winder is perfect for controlling your shutters at the push of a button. The belt winder is specially designed for flush-mounting and is universally applicable.The belt winder appears in a modern design. The intuitive display with illuminated symbol LEDs makes controlling the roller shutter belt winder child's play.Equipped with a memory function, it repeats the opening and closing times in a 24-hour cycle – so you can operate your shutters automatically in the morning and evening. Pretty comfortable!In addition, the electric belt winder fits in all common winder boxes from a width of 36 mm and can be easily connected to the 230 V power supply via a Euro connector. The soft-start and soft-stop function enables a smooth run with Hohem comfort.You can control the dependent upon the sun via our solar sensor.
This text is machine translated.
This text is machine translated.
Scope of delivery
- Belt winder RolloTron Classic Power
- 2 x mounting screws (4 x 55 mm)
- Release clip (in housing)
- Connection cable with Euro plug
- Winding wheel compartment cover
- Cover plate
- Strain relief including mounting screws.
