OBO Bettermann 2000003 Junction box (L x W) 43 mm x 80 mm 1 pc(s)
EAN:
Part number:
Item no:
Number
Total (€ 2.93 / piece)
€ 2.93
plus VAT.
14-day return policy included
Technical specifications
- Max. Conductor cross-section = 2.5 mm²
- Assembly = without
- The form = rectangular
- Mounting type = wall/ceiling mounting
- Introduction of rear = No
- Length = 43 mm
- Width = 80 mm
- Depth = 34 mm
- Can be stacked end-to-end = No
- The number of entries = 10
- The type of casing feed = Knockout
- Material = Plastic
- Halogen-free = Yes
- Surface = untreated
- Color = red
- IP55 degree of protection (IP) =
- Cover Mounting = snap-on
- Sealable = No
- Rated insulation voltage Ui=400 V.
- Function receives = without
- With Shielding = No
- Explosion tested design = No
- For Ex Zone Gas = without
- For Ex zone dust = without
- Product type
Junction box
- Features
Halogen-free
- Content
1 pc(s)
- Factory colour
Red
- Dim
(L x W) 43 mm x 80 mm
- Length
43 mm
- Width
80 mm
- Depth
34 mm
IP55
- Mounting
None
- UKCA
not relevant
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1957325 OBO Bettermann 2000003 Junction box (L x W) 43 mm x 80 mm 1 pc(s)
Description
The cable junction box has 6 inserts a cable diameters 7-14 mm and 4 inserts for a cable diameter 7-9 mm
