OBO Bettermann 2000422 Junction box (L x W) 100 mm x 125 mm 1 pc(s)

White junction box with multiple side entries. Markings such as '400V' and 'IP56' are visible on the front face.
Technical drawing of a rectangular enclosure with dimensions: width 129 mm, height 100 mm. Four round openings at the top.
1/2
EAN:
Part number:
Item no:
Dispatches on Thu 10 Dec
Sales and shipping:
Conrad ElectronicTerms & Conditions
Number
Total (€ 13.99 / piece)
€ 13.99
prav.tax.untaxed incl. VAT
plus € 19.99
prav.priceAvailability.ecoparticipation.cost ...
prav.priceAvailability.privatecopyingfee.cost ...
without further shipping costs
14-day return policy included
Report legal concerns

Technical specifications

  • Max. Conductor cross-section = 2.5 mm²
  • Assembly = without
  • The form = rectangular
  • Mounting type = wall/ceiling mounting
  • Introduction of rear = No
  • Length = 100 mm
  • Width = 125 mm
  • Depth = 40 mm
  • Can be stacked end-to-end = No
  • The number of entries = 18
  • The type of casing feed = Knockout
  • Material = Plastic
  • Halogen-free = Yes
  • Surface = untreated
  • Color = white
  • IP55 degree of protection (IP) =
  • Cover Mounting = snap-on
  • Sealable = No
  • Rated insulation voltage Ui=400 V.
  • Function receives = without
  • With Shielding = No
  • Explosion tested design = No
  • For Ex Zone Gas = without
  • For Ex zone dust = without
Product type

Junction box

Features

Halogen-free

Content

1 pc(s)

Factory colour

White

Dim

(L x W) 100 mm x 125 mm

Length

100 mm

Width

125 mm

Depth

40 mm

IP55

Mounting

None

Wall-/ceiling mounting

White

100

TRUE

40 mm

Square

Untreated

690 V

125 m

-5-45 °C

Plastic

FALSE

IP55

None

None

Blind cover

Documents & Downloads

User & Safety Instructions

User & Safety Instructions 1955950 OBO Bettermann 2000422 Junction box (L x W) 100 mm x 125 mm 1 pc(s)

Description

The cable junction box has 10 inserts a cable diameter of 7-14 mm and 8 entries for a cable diameter of 7-11 mm
