OBO Bettermann 2000164 Junction box (L x W) 85 mm x 85 mm 1 pc(s)
EAN:
Part number:
Item no:
Number
Total (€ 6.49 / piece)
€ 6.49
incl. VAT
14-day return policy included
Technical specifications
- Max. Conductor cross-section = 2.5 mm²
- Assembly = without
- The form = square
- Mounting type = wall/ceiling mounting
- Introduction of rear = No
- Length = 85 mm
- Width = 85 mm
- Depth = 40 mm
- Can be stacked end-to-end = No
- The number of entries = 12
- The type of casing feed = Knockout
- Material = Plastic
- Halogen-free = Yes
- Color = red
- Degree of protection (IP)=IP54
- Cover Mounting = snap-on
- Sealable = No
- Rated insulation voltage Ui=660 V
- Function receives = without
- With Shielding = No
- Weather-proof = No
- For Ex Zone Gas = without
- Product type
Junction box
- Features
Halogen-free
- Content
1 pc(s)
- Factory colour
Red
- Dim
(L x W x H) 85 x 85 x 40 mm
- Length
85 mm
- Width
85 mm
- Height
40 mm
- Depth
40 mm
IP54
- Mounting
None
- UKCA
yes
Documents & Downloads
User & Safety Instructions
User & Safety Instructions 1962643 OBO Bettermann 2000164 Junction box (L x W) 85 mm x 85 mm 1 pc(s)
Description
Halogen-free material, protection class IP 54, rated voltage 660, 12 inserts for cable diameters 8-14 mm. Terminal cover. Dimensions: 85 x 85 x 40 Internal dimensions: 75 x 75 x 35. Each 10 sockets 2 piercing punches.
This text is machine translated.
This text is machine translated.
