Phoenix Contact 1700121 Screw terminal 2.50 mm² Number of pins 3 Green 20 pc(s)
EAN:
Part number:
Item no:
Product type
Screw terminal
CS
5.00 mm
Pins per row
3
Number of pins
3
Connection
Screw terminal
Print
Datasheet (PDF)
Number (Package size 20 pc(s))
Total (€ 2.77 / piece)
€ 57.97
€ 55.45
plus VAT.
Only 8 Set(s) available
Highlights & Details
PCB terminal block FRONT 2,5-H/SA 5/ 3
- FRONT 2.5-H/SA5/3
- Industrial packaging with 20 pieces
Technical specifications
- Type
FRONT 2,5-H/SA 5/ 3
- Product type
Screw terminal
- CS
5.00 mm
- No. of rows
1
- Pins per row
3
- Number of pins
3
- Series
FRONT
- Stripping length (max.)
9.00 mm
- Connection
Screw terminal
Print
- Nominal current
24 A
- Cross section (flexible) (min.)
0.20 mm²
- Nominal current - rounded value
24 A
- Cross section (inflexible) (min.)
0.20 mm²
- Cross section (flexible) (max.)
2.50 mm²
- Cross section (inflexible) (max.)
2.50 mm²
- AWG (min.)
24
- Connector orientation
Parallel (to the PCB)
- AWG max.
14
- Contact material
Tin plated
- Enclosure material
Polyamide
- Factory colour
Green
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1700121
- Industrial packaging
Yes
- Content
20 pc(s)
- Nominal voltage
400 V
- Width
25.50 mm
- Height
19.50 mm
- Length
17.50 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 772388 Phoenix Contact 1700121 Screw terminal 2.50 mm² Number of pins 3 Green 20 pc(s)
User & Safety Instructions
User & Safety Instructions 772388 Phoenix Contact 1700121 Screw terminal 2.50 mm² Number of pins 3 Green 20 pc(s)
Description
PCB terminal block, Nominal current: 24 A, Nom. voltage: 400 V, Pitch: 5 mm, Number of positions: 3, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °, Color: green, The article can be aligned to create different nos. of positions!
