TracoPower TSP 090-148 EX Rail mounted PSU (DIN) 2000 mA 96 W No. of outputs:1 x Content 1 pc(s)
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 179.99 / piece)
€ 179.99
incl. VAT
14-day return policy included
Highlights & Details
AC/DC switching power supply, TSP series
- Robust design for harsh industrial environments
- For worldwide applications: Autorange input and int. Safety approvals
- ATEX and IECEx certification (extension -EX)
- Protection against short circuit,over voltage und overheating protection
- Adjustable output voltage:
- Shock and vibration-protected
- This text is machine translated.
Technical specifications
- Product type
Rail mounted PSU (DIN)
- Min. input voltage
85 V AC
- Input voltage (max.)
264 V AC
- Max. output current
2000 mA
- Output current (max.) - rounded
2 A
96 W
- Output type (power supply units)
Adjustable
- No. of outputs
1 x
- Connection
Screw terminal
- Dim
(L x W x H) 115.0 x 35.0 x 110.0 mm
- Weight
500 g
- Output voltage (max.)
+56.0 V DC
- Output voltage (min.)
+48.0 V DC
- Operating temperature (max.)
70 °C
- Min. operating temperature (derating)
40 °C
- Operating temperature (min.)
-25 °C
- Manufacturer part #
TSP 090-148 EX
- Content
1 pc(s)
- PSU features
ATEX certificate
- Width
35.0 mm
- Height
110.0 mm
- Length
115.0 mm
- Max. temperature
70 °C
- Min. temperature
-25 °C
- Type
TSP 090-148 EX
Documents & Downloads
Datasheet
Datasheet 1972343 TracoPower TSP 090-148 EX Rail mounted PSU (DIN) 2000 mA 96 W No. of outputs:1 x Content 1 pc(s)
Datasheet 1972343 TracoPower TSP 090-148 EX Rail mounted PSU (DIN) 2000 mA 96 W No. of outputs:1 x Content 1 pc(s)
User & Safety Instructions
User & Safety Instructions 1972343 TracoPower TSP 090-148 EX Rail mounted PSU (DIN) 2000 mA 96 W No. of outputs:1 x Content 1 pc(s)
