WAGO 250-724 2-tier terminal 1.00 mm² Number of pins 48 Grey 24 pc(s)
Product type
2-tier terminal
CS
5 mm
Pins per row
24
Number of pins
48
Connection
Spring-loaded terminal
Print
Datasheet (PDF)
EAN:
Part number:
Item no:
Total (€ 21.04 / piece)
€ 505.00
incl. VAT
14-day return policy included
Technical specifications
- PCB DOUBLE DECK TERM.STRIP 24 P. 5MM
- Type
250-724
- Product type
2-tier terminal
- Features
+ CAGE CLAMP®
+ actuator
- CS
5 mm
- No. of rows
2
- Pins per row
24
- Number of pins
48
- Series
250
- Min. stripping length
8 mm
- Stripping length (max.)
10 mm
- Connection
Spring-loaded terminal
Print
- Nominal current
10 A
- Cross section (flexible) (min.)
0.50 mm²
- Nominal current - rounded value
10 A
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
1.00 mm²
- Cross section (inflexible) (max.)
1.50 mm²
- AWG (min.)
20
- Connector orientation
At an angle (to the PCB)
- AWG max.
16
- Contact material
Cathode copper, tin plated
- Enclosure material
Polyamide
- Factory colour
Grey
- Wire protection
Yes
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
250-724
- Industrial packaging
Yes
- Content
24 pc(s)
- Nominal voltage
320 V
- Width
121.20 mm
- Height
24.90 mm
- Length
21.70 mm
Documents & Downloads
Datasheet
Datasheet 746096 WAGO 250-724 2-tier terminal 1.00 mm² Number of pins 48 Grey 24 pc(s)
User & Safety Instructions
User & Safety Instructions 746096 WAGO 250-724 2-tier terminal 1.00 mm² Number of pins 48 Grey 24 pc(s)
