Buy Phoenix Contact 1780015 Screw terminal 2.50 mm² Number of pins 1 Green 50 pc(s) | Conrad Electronic | Conrad Electronic » All parts of success

All things technology
Delivery within Europe
Right to Cancel applies
Specialist retailer since 1923

Green electrical terminal block with orange levers. Some levers are flipped upwards. Used for electronic connections.

Green electrical terminal block with orange levers. Some levers are flipped upwards. Used for electronic connections.

Image similar

Phoenix Contact

Product type

Screw terminal

CS

5.08 mm

Pins per row

1

Number of pins

1

Connection

Screw terminal

Print

Datasheet (PDF)

EAN:

Part number:

Item no:

Dispatches on Mon 16 Nov

431 Set(s)

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number (Package size 50 pc(s))

Set(s)

Total (€ 2.80 / piece)

€ 139.99

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

PCB terminal block KDS 3-MT

Content 50 pc(s)

Technical specifications

Type: KDS 3-MT

Product type: Screw terminal

Features: + extractor sleeve

CS: 5.08 mm

No. of rows: 1

Pins per row: 1

Number of pins: 1

Series: KDS

Stripping length (max.): 8.00 mm

Connection: Screw terminal
Print

Nominal current: 15 A

Cross section (flexible) (min.): 0.20 mm²

Nominal current - rounded value: 15 A

Cross section (inflexible) (min.): 0.20 mm²

Cross section (flexible) (max.): 2.50 mm²

Cross section (inflexible) (max.): 4.00 mm²

AWG (min.): 24

Connector orientation: Parallel (to the PCB)

AWG max.: 12

Contact material: Cathode copper, tin plated

Enclosure material: Polyamide

Factory colour: Green

Wire protection: Yes

Actuation direction: Perpendicular (to the PCB)

Manufacturer part #: 1780015

Industrial packaging: Yes

Content: 50 pc(s)

Nominal voltage: 320 V

Width: 28.30 mm

Height: 27.00 mm

Length: 5.08 mm

UKCA: yes

Documents & Downloads

Datasheet

Datasheet 717128 Phoenix Contact 1780015 Screw terminal 2.50 mm² Number of pins 1 Green 50 pc(s)

User & Safety Instructions

User & Safety Instructions 717128 Phoenix Contact 1780015 Screw terminal 2.50 mm² Number of pins 1 Green 50 pc(s)

Description

PCB terminal block, Nominal current: 15 A, Nom. voltage: 320 V, Pitch: 5.08 mm, Number of positions: 1, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °, Color: green, The article can be aligned to create different nos. of positions!

Description

PCB terminal block, Nominal current: 15 A, Nom. voltage: 320 V, Pitch: 5.08 mm, Number of positions: 1, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °, Color: green, The article can be aligned to create different nos. of positions!
