TracoPower TXL 060-3.3S SMPSU 3.3 V DC 15 A 60 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Number
Total (€ 67.22 / piece)
€
Highlights & Details
AC/DC power supply TracoPower TXL 060-3.3S 3.3 V/DC 15000 mA 60 W
- Model with single-output
Technical specifications
- Max. output current
15 A
- Output current (max.) - rounded
15 A
- Dim
(L x W x H) 38.0 x 95.0 x 169.0 mm
- Height
169.0 mm
- Length
38.0 mm
- Width
95.0 mm
- Connection
Screw terminal
- Type
closed
- Type
TXL 060-3.3S
- MTBF
250000 h
- Input voltage (max.)
264 V AC
- Min. input voltage
85 V AC
- Operating temperature (max.)
70 °C
- Max. operating temperature (derating)
45 °C
- Min. operating temperature (derating)
-20 °C
- Output current (min.)
0 mA
- Output voltage (max.)
3.3 V DC
- No. of outputs
1 x
60 W
- Type
Switched Mode
- Connection
Screw terminals
- PFC
Yes
- Input voltage
85 - 264 V AC
- Max. temperature
+70 °C
- Min. temperature
-10 °C
- Weight
700 g
- Product type
SMPSU
Documents & Downloads
Datasheet
Datasheet 2792667 TracoPower TXL 060-3.3S SMPSU 3.3 V DC 15 A 60 W
Warranty Terms
Warranty Terms 2792667 TracoPower TXL 060-3.3S SMPSU 3.3 V DC 15 A 60 W
Description
TracoPower TXL 060-3.3S
Features
- Compact metal casing with scew terminals
- Alignment range of output voltage ± 10%
- EMV Complaint EN 61000-6-3/-1 and EN 61000-3-2 (PFHC)
- Short circuit and surge protection
- Industrial quality standards
- Safety standards / approvals: cUL / UL 60950-1, IEC / EN 60950-1, CB-Report
- Line regulation ± 1% max
- Load stabilisation ±2% max
- Ripple <1% Vaus
- Short circuit protection 105 - 150% Iaus
- Overload protection Foldback, automatic restart
- Operating temperature -10 to +60° C.
Hints
Derating >45 °C.
