TracoPower TXL 750-24S SMPSU 24 V DC 31.3 A 750 W
EAN:
Part number:
Item no:
Datasheet (PDF)
Show alternatives
Sales and shipping:
Number
Total (€ 357.14 / piece)
€
Highlights & Details
Installation-power supplies TXL-Series, 15 - 1000 W
- Model with single-output
Technical specifications
- Max. output current
31.3 A
- Output current (max.) - rounded
31.3 A
- Dim
(L x W x H) 275 x 113 x 63 mm
- Height
63 mm
- Length
275 mm
- Width
113 mm
- Connection
Screw terminal
- Type
closed
- Type
TXL 750-24S
- MTBF
250000 h
- Input voltage (max.)
264 V AC
- Min. input voltage
85 V AC
- Output voltage (max.)
24 V DC
- No. of outputs
1 x
750 W
- Type
Switched Mode
- Connection
Screw terminals
- PFC
Yes
- Input voltage
85 - 264 V AC
- Max. temperature
+70 °C
- Min. temperature
-10 °C
- Product type
SMPSU
Documents & Downloads
Datasheet
Datasheet 2789950 TracoPower TXL 750-24S SMPSU 24 V DC 31.3 A 750 W
Datasheet 2789950 TracoPower TXL 750-24S SMPSU 24 V DC 31.3 A 750 W
Warranty Terms
Warranty Terms 2789950 TracoPower TXL 750-24S SMPSU 24 V DC 31.3 A 750 W
Description
TracoPower TXL 750-24S
Features
- Compact metal casing with scew terminals
- Alignment range of output voltage ± 10%
- EMV Complaint EN 61000-6-3/-1 and EN 61000-3-2 (PFHC)
- Short circuit and surge protection
- Industrial quality standards
- Safety standards / approvals: cUL / UL 60950-1, IEC / EN 60950-1, CB-Report
- Line regulation ± 1% max
- Load stabilisation ±2% max
- Ripple <1% Vaus
- Short circuit protection 105 - 150% Iaus
- Overload protection Foldback, automatic restart
- Operating temperature -10 to +60° C.
Hints
Derating >45 °C.
