Image similar
Phoenix Contact 1709733 Screw terminal 16.00 mm² Number of pins 7 Green 50 pc(s)
Product type
Screw terminal
CS
10.16 mm
Pins per row
7
Number of pins
7
Connection
Screw terminal
Print
Datasheet (PDF)
EAN:
Part number:
Item no:
Number (Package size 50 pc(s))
Total (€ 18.58 / piece)
€ 929.00
incl. VAT
14-day return policy included
Highlights & Details
Single PCB terminal block MKDS 10 HV/ 7-ZB-10,16
- Content 50 pc(s)
Technical specifications
- Type
MKDS 10 HV/ 7-ZB-10,16
- Product type
Screw terminal
- Features
+ extractor sleeve
- CS
10.16 mm
- Pins per row
7
- Number of pins
7
- Series
MKDS
- Stripping length (max.)
10.00 mm
- Connection
Screw terminal
Print
- Nominal current
76 A
- Cross section (flexible) (min.)
0.50 mm²
- Nominal current - rounded value
76 A
- Cross section (inflexible) (min.)
0.50 mm²
- Cross section (flexible) (max.)
16.00 mm²
- Cross section (inflexible) (max.)
16.00 mm²
- AWG (min.)
20
- Connector orientation
Parallel (to the PCB)
- AWG max.
6
- Contact material
Tin plated
- Factory colour
Green
- Actuation direction
Perpendicular (to the PCB)
- Manufacturer part #
1709733
- Industrial packaging
Yes
- Content
50 pc(s)
- Nominal voltage
1000 V
- Width
71.12 mm
- Height
35.80 mm
- Length
18.70 mm
- UKCA
yes
Documents & Downloads
Datasheet
Datasheet 567543 Phoenix Contact 1709733 Screw terminal 16.00 mm² Number of pins 7 Green 50 pc(s)
User & Safety Instructions
User & Safety Instructions 567543 Phoenix Contact 1709733 Screw terminal 16.00 mm² Number of pins 7 Green 50 pc(s)
Description
PCB terminal block, Nominal current: 76 A, Nom. voltage: 1000 V, Pitch: 10.16 mm, Number of positions: 7, Connection method: Screw connection, Mounting: Soldering, Conductor/PCB connection direction: 0 °, Color: green
Hints
Special order, no right of withdrawal.
