Picotronic Laser module Line Green 10 mW LFL 532-10-3 (12x60)
Product type
Laser module
Emission characteristics
Line
Wavelength
532 nm
Power
10 mW
Laser category
2
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 275.00 / piece)
€ 275.00
incl. VAT
14-day return policy included
Highlights & Details
Laser module line
- Green
- Laser category: 2
- Emission characteristics: Line
Technical specifications
- Connection cable 100 mm
- Product type
Laser module
- Type
LFL 532-10-3 (12x60)
- Emission characteristics
Line
- Focus properties
3000 mm fixed-focus
- Factory colour
Green
- Wavelength
532 nm
10 mW
- Laser category
2
- Angular aperture
90°
- Beam divergence
0.5 mrad
- Clearance
5 m
- Operating voltage
3 V DC
- Operating current
210 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+30 °C
- Min. temperature
-15 °C
Documents & Downloads
Datasheet
Datasheet 1695917 Picotronic Laser module Line Green 10 mW LFL 532-10-3 (12x60)
User & Safety Instructions
User & Safety Instructions 1695917 Picotronic Laser module Line Green 10 mW LFL 532-10-3 (12x60)
Information
Information 1695917 Picotronic Laser module Line Green 10 mW LFL 532-10-3 (12x60)
Conformity certificate
Conformity certificate 1695917 Picotronic Laser module Line Green 10 mW LFL 532-10-3 (12x60)
Description
Hints
Class 2 laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
