Picotronic Laser module Line Green 1 mW LE 520-1-3 (14x45) 90 DEG F 150 - QCW
Product type
Laser module
Emission characteristics
Line
Wavelength
520 nm
Power
1 mW
Laser category
1M
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 419.00 / piece)
€ 419.00
incl. VAT
Only 2 Piece(s) available
Highlights & Details
Laser module line
- Green
- Laser category: 1M
- Emission characteristics: Line
Technical specifications
- Connection cable 100 mm
- Product type
Laser module
- Type
LE 520-1-3 (14x45) 90 DEG F 150 - QCW
- Emission characteristics
Line
- Focus properties
150 mm fixed-focus
- Factory colour
Green
- Wavelength
520 nm
1 mW
- Laser category
1M
- Angular aperture
90°
- Beam divergence
0.6 mrad
- Clearance
0.15 m
- Operating voltage
3 V DC
- Operating current
200 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+60 °C
- Min. temperature
-10 °C
Documents & Downloads
Datasheet
Datasheet 1696011 Picotronic Laser module Line Green 1 mW LE 520-1-3 (14x45) 90 DEG F 150 - QCW
User & Safety Instructions
User & Safety Instructions 1696011 Picotronic Laser module Line Green 1 mW LE 520-1-3 (14x45) 90 DEG F 150 - QCW
Information
Information 1696011 Picotronic Laser module Line Green 1 mW LE 520-1-3 (14x45) 90 DEG F 150 - QCW
Conformity certificate
Conformity certificate 1696011 Picotronic Laser module Line Green 1 mW LE 520-1-3 (14x45) 90 DEG F 150 - QCW
Description
Hints
Class 1M: laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
