Name: Siemens 3VA2116-8HM32-0AA0 Circuit breaker 1 pc(s) Adjustment range (amperage): 63 - 160 A Switching voltage (max.): 690
Brand: Siemens
SKU: 1725713
Availability: BackOrder

A three-pole Siemens circuit breaker, Model 3VA2, grey-black, for electronic protection functions in electrical installations.

Technical drawing of an electrical switch with front and side view. Dimensions in millimetres, showing details of design measurements.

1/2

Image similar

Product type

Circuit breaker

Amperage adjustment range (max.)

160 A

Connection

Screws

Type

3VA2116-8HM32-0AA0

Amperage adjustment range (min.)

63 A

Datasheet (PDF)

Dispatches on Wed 28 Oct

Sales and shipping:

Conrad ElectronicTerms & Conditions

Number

Piece(s)

Total (€ 1,505.00 / piece)

€ 1,505.00

incl. VAT

14-day return policy included

Report legal concerns

Highlights & Details

MCCB_IEC_FS160_160A_3P_150KA_ETU8_LSI

Our service for you

Technical specifications

Design: System Protection
Power loss: 19.7 W
Weight: 2.29 kg
Mechanical life: 20000
Electrical life: 12000
Isolation voltage: 800 V
Mains frequency: 50/60 Hz.

Product type: Circuit breaker

Type: 3VA2116-8HM32-0AA0

Amperage adjustment range (min.): 63 A

Amperage adjustment range (max.): 160 A

Adjustment range (amperage): 63 - 160 A

No. of pins: 3-pin

Switching voltage (max.): 690 V AC

Compatible with series: Siemens 3VA series

Compatible with: Siemens

Mounting type: Fixed

Min. temperature: -25 °C

Max. temperature: +70 °C

Breaking capacity rating: L

OCR type: ETU330

Connection: Screws

: IP40

Depth: 86 mm

Width: 105 mm

Height: 181 mm

Dim: (W x H x D) 105 x 181 x 86 mm

Content: 1 pc(s)

RoHS-compliant: Yes

: 0

: 0

: 160 A

: 3

: 63-160 A

: 0

: 690-690 V

: 19.7 W

: IP40

: Front side

: FALSE

: Screw connection

: Rocker lever

: FALSE

: 150 kA

: 240-1600 A

: TRUE

: TRUE

: TRUE

: Built-in device fixed built-in technique

: TRUE
