Picotronic Laser module Line Red 15 mW LB 650-15-230 (40 x 210)-F5000
Product type
Laser module
Emission characteristics
Line
Wavelength
650 nm
Power
15 mW
Laser category
2
Datasheet (PDF)
EAN:
Part number:
Item no:
Number
Total (€ 635.00 / piece)
€ 635.00
incl. VAT
Only 8 Piece(s) available
Highlights & Details
Laser module line
- Red
- Laser category: 2
- Emission characteristics: Line
Technical specifications
- Earthing contact plug 1750 mm
- Product type
Laser module
- Type
LB 650-15-230 (40 x 210)-F5000
- Emission characteristics
Line
- Focus properties
5000 mm fixed-focus
- Factory colour
Red
- Wavelength
650 nm
15 mW
- Laser category
2
- Angular aperture
90°
- Beam divergence
0.3 mrad
- Clearance
5 m
- Operating voltage
230 V AC
- Operating current
10 mA
- Material
Aluminium
- RoHS-compliant
Yes
- Max. temperature
+50 °C
- Min. temperature
-20 °C
Documents & Downloads
Datasheet
Datasheet 1695839 Picotronic Laser module Line Red 15 mW LB 650-15-230 (40 x 210)-F5000
User & Safety Instructions
User & Safety Instructions 1695839 Picotronic Laser module Line Red 15 mW LB 650-15-230 (40 x 210)-F5000
Information
Information 1695839 Picotronic Laser module Line Red 15 mW LB 650-15-230 (40 x 210)-F5000
Conformity certificate
Conformity certificate 1695839 Picotronic Laser module Line Red 15 mW LB 650-15-230 (40 x 210)-F5000
Description
Hints
Class 2 laser beam! Observe safety instructions! Never look into the beam (may damage your retina).
