Name: ifm Electronic Electronic fluid level gauge LR2750 LR2750 Operating voltage (range): 18 - 30 V DC Reading range: 0.02 -
Brand: ifm Electronic
SKU: 3321857

A stainless steel sensor with a digital display and orange buttons, suitable for industrial applications, against a black background.

Image similar

Product type

Electronic fluid level gauge

Min. operating voltage

18 V DC

Max. operating voltage

30 V DC

Reading range (max.)

1.98 m

Type

LR2750

Datasheet (PDF)

EAN:

Part number:

Item no:

Unavailable

Sales and shipping:

Conrad ElectronicTerms & Conditions

Report legal concerns

Technical specifications

Product type: Electronic fluid level gauge

Type: LR2750

Min. operating voltage: 18 V DC

Max. operating voltage: 30 V DC

Operating voltage: 18 - 30 V DC

Features: LED indicator

Connector: M12

Outputs: PNP
NPN

Material: Stainless steel

Sealant: EPDM

Enclosure material: Stainless steel V4A

Media temperature (min.): -40 °C

Max. media temperature: 150 °C

Max. operating pressure: 40 bar

Accuracy ±: 7 mm

Reading range (min.): 0.02 m

Reading range (max.): 1.98 m

Reading range: 0.02 - 1.98 m

: IP68

Weight: 0.4010 kg

Min. ambient temperature: -40 °C

Max. ambient temperature: 80 °C

Content: 1 pc(s)

RoHS-compliant: Yes

UKCA: yes
